What does the term ‘engine misfire’ imply? The engine not firing properly indicates that one or more of the engine’s cylinders do not have combustion. Various engine codes warn us about the misfiring of engine cylinders. What engine code will appear if the first cylinder of the engine keeps misfiring? It usually is the P0301 code!

via GIPHY

Intermittent misfire occurs when the cylinder misfires only under certain circumstances and not all of the time. In comparison, code P0300 indicates random misfires in multiple cylinders, and codes P0302, P0303, and P0304 show misfires in cylinders 2, 3, and 4. The PCM identifies the ‘misfiring’ by monitoring the engine speed.

So, what is the P0301 code? What causes it? How serious is the error code? How can you fix it and how much to spend on that? Here’s all the info you need!

What does code P0301 mean?

You’ll get a P0301 code if the first cylinder in your engine misfires. Combustion reactions provide the energy for an engine’s drivetrain. When combustion fails in the cylinders, you’ll experience a misfire, which is indicated by a sudden drop in RPMs when your engine cannot produce adequate power.

The powertrain control module (PCM) will store the P0301 engine code if it detects a larger than 2 percent increase or decrease in crankshaft rotations per minute. The Check Engine Light gets on if the percentage of increase or reduction in crankshaft rotations per minute is between 2 and 10 percent. The Check Engine Light will flash if the proportion of increase or reduction in crankshaft rotations per minute is greater than 10 percent.

A larger than 10% increase or reduction in revolutions per minute suggests that the misfiring problem is severe.

What causes a P0301 code?

Various reasons can lead to cylinder misfiring. It can be due to internal engine failure or a malfunctioning ignition or fuel system. But, the ideal reason for the P0301 code to appear may be a worn-out or defective spark plug coil pack. It normally happens if you haven’t had a car service for a while. These are some factors that can lead to engine error code P0301.

• Defective or worn-out spark plug/plugs
• Issues with ignition like faulty ignition coils
• Damaged fuel injector
• Fuel pressure is low
• Vacuum leakage
• Faulty camshaft and/or crankshaft sensors
• Distributor failure
• Engine timing gets off
• The presence of poor quality fuel that is polluted or old
• Leak in head gasket
• Engine compression gets low
• A lean air or fuel mixture causing a defective airflow sensor
• Valve misalignment and misadjustment
• Worn-out valve train components
• Blocked exhaust
• Purge valve (solenoid) and/or EGR valve stuck open

Symptoms of P0301 code

The most common symptom is that the Check Engine Light turns on. These are some of your car’s symptoms when it gets the P0301 engine code.

• The Check Engine Light gets on or starts flashing
• The car is difficult to start or does not start at all during acceleration
• The car’s engine is rough, and it idles rough
• The car loses power while in operation, stalls, or dies while stopped
• Increase in fuel consumption
• Experiences fuel smell from exhaust
• The car has a jerking motion when idle or moving

How serious is the P0301 engine code? 

You should never ignore the P0301 engine code. Cylindrical misfires can cause serious engine damage if you ignore them. Severe misfiring of the cylinder can damage the catalytic converter, causing the malfunction indicator lamp (MIL) to flash. As the component is vital for a car engine’s proper functioning and catalytic converter replacement is expensive, you should take the car to a trained mechanic as soon as the code appears.

Is it safe to drive with a P0301 code?

You should not drive with a code P0301 set since a misfire can cause additional damage to your car. You should deal with the problem right away, taking the car to a mechanic. If the Check Engine Light is flashing, the car is dealing with severe cylinder misfiring. So, better not to drive forward.

How to diagnose code P0301

Take your car to an expert mechanic when your car shows any of the P0301 code symptoms. It is vital to diagnose the issue before fixing it.

Steps followed by the mechanic to diagnose the code

• Using an OBD-II scanner collects all PCM fault codes and freezes frame data
• Test drive the car to see if the P0301 code returns
• Examine for damage or wear on the cylinder 1 spark plug wire
• Inspects the spark plug cylinder for damage
• Examines the coil packs and coil pack wires for damage or wear
• Replace spark plugs, coil packs, and coil pack wiring if needed. Inspect the fuel injectors and fuel injectors for damage if the code returns after replacing these components
• Checks for rust or cracks in the distributor cap and/or rotor button
• Diagnoses and repairs relevant codes to the P0301 code stored by the PCM.
• Does a test drive again to check if the code persists
• If the error code returns, inspect the compression system of cylinder 1
• The powertrain control module may be faulty if the P0301 code persists. Then replace or reprogram the PCM

Common mistakes that can happen during diagnosis

Examine the fuel injector wiring for damage before replacing the spark plugs, spark plug wires, coil packs, and coil pack wires. Although damaged fuel injectors are unusual, a quick visual check could save time. Determine that a faulty cylinder is not the source of the issue. It’s also critical to diagnose and repair other associated issue codes saved by the powertrain control module. Any of these components may be causing the misfire.

How to fix the P0301 code

Fixing the misfire depends on the cause, so it is critical to get the issue thoroughly diagnosed. You don’t wish to spend a lot of money buying new parts for your car. Even if you want to make the repairs yourself, we recommend that you have it diagnosed by your dealer or a reputable repair shop.

Check all wiring and connectors that link to the cylinders, such as the spark plugs, to fix engine stumbling or hesitation. Replace the ignition components if it has been in the car for a long time. Also, replace the spark plugs and their wires, as well as the distributor cap and rotor if required. If the exhaust has a bad odor, inspect the cat converter and replace it if necessary. Faulty fuel injectors can also cause the code to appear.

After fixing the misfiring, the code will disappear after a few miles of driving.

What repairs can fix the P0301 code?

Do the following replacements or repairs for these components to fix the engine code P0301. 

• Faulty spark plugs, spark plug wires, or coils
• Clogged EGR valves and/or tubes
• Burned valves
• Vacuum leaks
• Leaking head gaskets
• Faulty camshaft sensor
• Faulty crankshaft sensor
• Damaged mass airflow sensor, oxygen sensor, and throttle position sensor
• Defective catalytic converter
• Faulty fuel injectors

Also, try these to fix the engine code trouble.

• Other than the wires, coils, and plugs, replace the distributor cap and rotor button.
• If necessary, diagnose other related engine codes and repair
• Doing necessary repairs to internal engine components
• Replace the engine if there is damage to the cylinder
• If required, reprogram or replace the PCM 

How much does it cost to fix code P0301?

Various factors can lead to the P0301 code, like worn spark plugs, low engine compression, and vacuum leaks. So, it’s hard to provide an accurate cost without first effectively assessing the problem.

Most shops will begin with an hour of ‘diag time’ when you take your car in for a diagnosis. Depending on the shop’s labor rate, it can cost anywhere from $75 to $150. If the shop conducts the repairs for you, they will apply this diagnosis cost to other required repairs.

P0301 may need one or more of the following repairs to solve the primary issue if properly detected. These prices include components and labor based on national averages. The repair cost will differ depending on your location and car type.

Estimated costs

Item	Estimated cost
Spark plugs	$66-250
Spark plug wires	$180-240
Fuel injectors	$1500-$1900
Ignition coils	$230-$640
Vacuum leak	$100-$200
Fuel pump	$1300-$1700
Fuel pressure regulator	$200-$400

How do I fix code P0301?

It is impossible to fix this problem on your own unless you have a mechanical background. You can, however, inspect your engine to try to find out the cause of the problem. Look for the following symptoms of damage when inspecting your engine cylinder. 

• Presence of corroded electrical connectors
• Broken, bent, or misplaced components
• Fluids leaking from the cylinder

You may be able to fix the misfire problem by replacing the cylinder’s spark plugs. Consult a mechanic if the problem remains after installing the new plugs.

Will a P0301 code clear itself?

Once you do the needed repair for the issue and it gets no longer detected, the misfiring code will clear itself after some driving.

Finding the right insurance for your car

Severe misfiring of the cylinder can cause damage to your car’s catalytic converter. Unfortunately, repairing or replacing a catalytic converter is very expensive. So, you need to find insurance that provides coverage for catalytic converter replacement. And that’s where Way.com turns into your best friend! So, you can decrease your auto insurance costs while getting the coverage you need.

What’s more? There’s no need to visit any insurance office or fill up any forms. Instead, download the Way.com app, answer a few questions, and we’ll take care of the rest!

The bottom line

• Cylinder 1 misfires when the P0301 engine code shows up.
• You need to stop driving immediately when the code appears.
• To avoid ignition failure, catalytic converter damage, and unsafe situations, fix this code as soon as possible (preferably the same day).
• Various factors can trigger misfires, including defective spark plugs and insufficient engine compression. Since there are so many factors that can cause a misfire, the best way to save your money is to take your car to a mechanic and fix the issue.

---
